Xnova Lightning 4030-1000kV Brushless Motor (Shaft A)

This is the Xnova Lightning 4030-1000KV 1.5Y Brushless Motor with a 6mm “Type A” 38mm Shaft. This high performance brushless motor was developed for 3D flying on 6-7S on the SAB Raw 700 PIUMA helicopter.

NOTE: For operation on 6S (20T motor pulley) or 7S (18T or 19T motor pulley).

Features:

• Higher efficiency over previous generation
• Thinner stator laminations
• Lower temperatures
• Smooth operation; no cogging
• Specialized wires,heat resistance up to 250 degree C
• Precision balanced
• High performance stator metal sheet
• Optimized ventilation
• High quality NMB bearings
• Superb quality and machining of CNC parts

Specifications:

Slots and Poles: 24n8p

Winding T: 1.5Y

rpm/V: 1000

Volt (V): 10 | 20 | 25

Io(A): 3.1 | 5.1 | 5.3

Rm (mohm): 7 | 7 | 7

Weight (without connector): 435g

Body Length (no shaft): 61.2mm

Diameter: 49.5mm

Shaft Length: 38mm

Shaft Diameter: 6mm

Max Eff. Curr.: 66.55 | 120.71 | 137.58

Max Eff.: 90.68 | 91.55 | 92.30

Kt (Nm/A): 0.0095

Km (Nm/sqrt(w)): 0.1141

Max Continuous Power (Watts): 3500

Peak Continuous Power (Watts) (5 sec): 6900

Max cont. current (A): 100

Includes:

• (1) Xnova Lightning 4030-1000KV 1.5Y Brushless Motor
• (6) Bullet Connectors (3 Female and 3 Male)
